Overview

The micro brewery was manufactured in 1999 by theGerman manufacturer BERAPLAN. All equipment is in good condition. A new wort copper was added in 2018.

List of equipment:

1. Mash Tun

• Made by Beraplan in 1999
• Cylindric shape with conical ground
• Material: stainless steel AISI 304
• Inner diameter: 2000 mm
• Height: 1600 mm
• Height conical part: 20 0mm
• Volume: maximum 38 Hl
• Double sidewall
• Insulation
• Heated by steam, which can be regulated
• Hot and cold water inlet at the bottom
• Can be emptied through the bottom
• 4 CIP balls
• PT100
• 2 agitators
• Mach pump with variable speed drive

2. Lauter Tun

• Made by Beraplan in 1999
• Cylindric shape with flat ground
• Material: stainless steel AISI 304
• Inner diameter: 2000 mm
• Height: 1200 mm
• Volume: maximum 37 Hl
• Filtering ground with trapezoidal perforations
• High precision valve to regulate the flow rate
• Hot and cold water inlet at the bottom
• 4 CIP balls
• PT100

3. Wort Copper

• Made by FRACCHIOLLA in 2018
• Heated by steam
• Cleanning balls
• Temperature sensor
• Transfer pump from Alfa Laval Solid C-2 (3 kW)

4. Whirlpool

• Made by Beraplan in 1999
• Cylindric shape with flat ground
• Material: stainless steel AISI 304
• Inner diameter: 2000 mm
• Height: 1250 mm
• Volume: maximum 40 Hl
• Double sidewall
• CIP balls
• Transfer pump from Alfa Laval Solid C-2 (2,2 kW)

5. Hot Water Tank

• Cylindric shape with flat ground
• Material: stainless steel AISI 304
• Inner diameter: 2000 mm
• Height: 2700 mm
• Volume: maximum 85 Hl
• Double sidewall
• CIP balls
• Transfer pump from Alfa Laval Solid C-2 (7,5 kW)
• Heated by steam with temperature regulation

6. Heat Exchanger

• Made by MDC (France)
• Plate heat exchanger double zone model: RDC 307
• Capacity: 30 Hl/h from 85°C to 16°C

7. Ice Water Unit

• Capacity: 1000 l
• New pump
