Overview

This complete filling line for cans was installed at the end of 2021 and commissioned in January 2022. All machines - with the exception of the tray packaging machine, which was installed as a second-hand machine - were brand new. The line is still in production until around March and can be viewed in person at any time.

Technical details

• Output: 3,000 cans per hour
• Formats:
  • 200 ml slim
  • 250 ml slim
  • 330 ml sleek
  • 330 ml standard
  • 440 ml standard
• The filler can work with carbonated and non-carbonated beverages and has a nitrogen dosing system

Machine list

1. Semi-automatic depalletizer
2. Twistrinser for rinsing the cans
3. Counter-pressure filling machine | EUROSTAR | CANFILL 9 ONE | 2021
   • with 9 filling valves and one capping head
4. Nitrogen dosing for filling non-carbonated beverages
5. External shower and drying of the cans after the filler.
6. Bottom-up can turning device
7. Inkjet printer Bluhm Systems
8. Rotary table
9. Chamber pasteurizer | Kreuzmayer | KKP 360 | 2021
   • Finally, 5 stainless steel trolleys were used: hold approx. 1800 cans per trolley for 250ml slim and 1400 cans per trolley for standard format
10. Turntable
11. Drying device
12. Labeler for a self-adhesive label | STM Sp. z.o.o. | 2022
13. Shrink tunnel for full body labels
    • Only works with slim and sleek cans, unfortunately not with standard - only half-body labels
14. Tray packaging machine | PACTEC | PTF 28W | 2006
15. for 24-pack trays
