Overview

The offered filling line for pouch bags was designed by a Swiss company and also delivered by them in 2018. The main manufacturer is Linapack. The line was only used for seasonal production only (2 months a year), therefore the working hours are very low. As the sales volumes are not further increasing, the seller decided to sell the line and stop the production. The line is still assembled and can be shown.

It is possible to handle different formats of pouch bags and to do hot filling up to 85°C. The current owner used it for Cocktails but it can also be used for various other non carbonated drinks.

Tech. Details

• Capacity:
  • 50 bags/ hour, depending on the volume
  • 750 -900 l/h
• Bag dimensions
  • Width: 80 - 180mm
  • Height: 100 - 300mm
• Filling temperature: 71 - 85 °C
• Siemens PLC

Line consists of

• 1,000 l buffer tank
  • agitator
  • Flow meter
  • Level detection
  • Cleaning spray ball
  • Integrated into pasteurizer control system
• Flash pasteurizer Kreuzmayr PAS-900
  • Capacity: 750 - 1,000 l/h
  • Heated with steam
  • Fully automatic
  • Automatic cleaning with
    • Hot water
    • steam
    • acid
    • caustic
• With tubular heat exchanger
• Automatic filler Linapack LFS-1000 Duplex
  • with Siemens PLC
  • Seven Station system
    1. motorized magazine with pick and place system to supply pouches
    2. Opening of the pouches with vacuum gripper
    3. Filling unit with flow meter and temperature sensor, automated rejection, if temperature is too low
    4. Sealing of pouches
    5. Sealing of pouches
    6. Cooling of the seal
    7. Pouch discharge
• Check weigher
• Cooler and dryer for pouches
  • Cooling in water bath
  • With UV lamps for desinfication
  • Drying by blower, five nozzles
• Conveyors and collection table
